Conventional TXC7012 Fire Alarm Control Panel

Name: Conventional TXC7012 Fire Alarm Control Panel - Hacsons
SKU: TXC7012
Price: 55000.00 PKR
Availability: InStock

SKU: TXC7012

The TXC7000 Series by T&A is a robust, user-friendly line of conventional fire alarm control panels designed for small to medium-sized buildings. Fully compliant with EN54-2, these panels provide reliable fire detection, alarm signaling, and operational simplicity across multiple detection zones. The TXC7012 model supports up to 12 zones, with each zone accommodating up to 30 devices, making it suitable for a wide range of applications including offices, schools, warehouses, and light industrial sites.

₨55,000.00

Add to compare

Add to wishlist

Shipping and returns

Products must be returned undamaged within 7 days of delivery. Cartridge charges incurred after receiving the order are the customer’s responsibility. Shipping costs for returns are non-refundable.

Payment Info

Thank you for Shopping with us! Bank Transfer or ATM Cash Deposit: You may transfer the total order amount using Online bank transfer from any of your Pakistani Bank Online Portal. Our Bank Account details are as follows: Bank Name: HBL Account No: 58517000019103 Account Name: HAC & SONS Please send an email to sa@hacsons.com with the payment reference number or confirmation once the amount has been transferred.

Product details

Operating Voltage	AC 220V (Range: 187V ~ 242V), 50Hz
Quiescent Current	≤ 65μA (Detector quiescent current)
Alarm Current	Panel Bell Output: 0.5A per zone
Remote LED Output Current	Max. 20mA (via connected detectors)
Alarm Indication	Red LED per zone (Continuous On)
Normal Indication	Green LED per zone (Blinking)
Operating Temperature	0°C to +40°C
Relative Humidity	≤ 95% RH, Non-condensing
Maximum Air Velocity	Not applicable (panel, not sensor)
Weight	1.5kg

Data Sheet

Description

EN54-2 Certified Compliance: Designed in full accordance with international fire safety standards.
Flexible Zone Configuration: Available in 1, 2, 4, 8, or 12-zone models (TXC7001–TXC7012), each supporting up to 30 conventional devices.
Wide Compatibility: Compatible with conventional detectors (TXC7101, TXC7111), manual call points (TXC7141), and sounder strobes (TXC7301).
Reliable Power Supply: Equipped with a 12.8V, 4Ah backup battery for uninterrupted operation during mains power failure.
Multiple Output Terminals: Dedicated outputs for sounders, strobe lights, auxiliary devices, and fault signaling.
User-Friendly Interface: Simple front panel operation and LED indicators for zone status and faults.
RS485 Communication Port: Reserved for future integration with external communication or monitoring systems.
Durable Build: Industrial-grade design suitable for wall mounting in control rooms or accessible locations.
