Product details
| Specification | Details |
|---|---|
| Conductor | 16 AWG solid bare copper (1/1.292 ± 0.008 mm) |
| Nominal Diameter | 0.0509 ± 0.0003″ (1.292 ± 0.008 mm) |
| Insulation Type | Polyvinyl Chloride (PVC) |
| Diameter over Insulation | 0.0847 ± 0.0040″ (2.15 ± 0.10 mm) |
| Drain Wire | 1/0.404 ± 0.008 mm solid tinned copper |
| Shield | Aluminum/Mylar, 0.001″ (0.025 mm) thick |
| Jacket Material | PVC (Red, White, or other colors) |
| Diameter over Jacket | 0.2408 ± 0.0118″ (6.1 ± 0.3 mm) |
| Temperature Rating | -20 °C ~ +105 °C |
| Operating Voltage | 300 V maximum |
| Withstand Voltage Test | DC 2500 V / 2 s (no breakdown) |
| Insulation Resistance | ≥ 100 MΩ/KFT at 15.6 °C |
| Conductor Resistance | ≤ 13.5 Ω/km at 20 °C |
| Standards Compliance | UL 1581, UL 2556, UL 1666 |
| Marking | Fire Alarm Cable (UL) E… FPLR 105 °C 3C/16AWG LLT Date |
Description
The 16 AWG Fire Alarm Cable is a high-performance communication and control cable designed to meet the demanding requirements of fire detection and alarm systems. Constructed with a solid bare copper conductor and insulated with durable polyvinyl chloride (PVC), it ensures excellent electrical conductivity and thermal stability. The cable features a reliable aluminum/mylar shield with a tinned copper drain wire to provide superior protection against electromagnetic interference, ensuring accurate signal transmission in critical applications. The robust PVC jacket, available in red, white, or other colors, enhances mechanical strength and flame resistance, making the cable ideal for use in commercial and industrial environments such as offices, airports, tunnels, and control centers. With compliance to UL 1581, UL 2556, and UL 1666 standards, this cable guarantees safety, reliability, and consistent performance even under harsh operating conditions, supporting a temperature range from -20 °C to +105 °C and a maximum voltage of 300 V.
-
Reliable Construction: Solid bare copper conductor ensures superior conductivity and signal integrity.
-
Durable Insulation: PVC insulation provides excellent electrical and mechanical protection.
-
Effective Shielding: Aluminum/Mylar shield with tinned copper drain wire minimizes EMI and RFI interference.
-
Temperature Resilience: Designed for continuous operation from -20 °C to +105 °C.
-
Flame Retardant: Meets UL 1581, UL 2556, and UL 1666 flame propagation standards.
-
High Electrical Performance: Withstands 2500 V DC without breakdown and maintains ≥ 100 MΩ insulation resistance.
-
Versatile Applications: Suitable for fire alarm, control, and communication systems in commercial and industrial settings.
-
Flexible Packaging: Available in drums, cartons, or palletized formats per international standards.
