Product details
| Model | TXC7004 |
|---|---|
| Zones | 4 |
| Input Voltage | AC 220V (Range: 187V ~ 242V), 50Hz |
| Main Circuit Current | 2.8A |
| Backup Battery | 12.8V, 4Ah |
| Zone Device Capacity | 30 Devices per Zone |
| Alarm Bell Output | 0.5A per Zone |
| Auxiliary Power Outputs | 2 Outputs (0.5A each) |
| Dimensions (L × W × H) | 311mm × 60mm × 251mm |
| Weight | 1.5kg |
Description
The TXC7004 is a 4-zone model from the robust TXC7000 Series of conventional fire alarm control panels by T&A Fire Systems. Fully compliant with the EN54-2 standard, this panel is purpose-built for small to mid-sized buildings like offices, schools, warehouses, and retail environments. It supports up to 30 devices per zone, ensuring scalable protection across multiple areas. With an intuitive interface, dedicated outputs for alarm and auxiliary devices, and built-in power backup, the TXC7004 combines reliability, flexibility, and simplicity in a compact, industrial-grade housing. Whether you’re upgrading an existing system or installing new infrastructure, the TXC7004 offers easy integration with conventional detectors, call points, and sounder strobes.
-
EN54-2 Certified for international fire safety compliance
-
4-Zone Configuration with support for up to 30 devices per zone
-
Compatible with conventional detectors (TXC7101, TXC7111), call points (TXC7141), and sounder strobes (TXC7301)
-
Integrated 12.8V, 4Ah battery backup for power loss resilience
-
Dual alarm outputs for sounders or strobe devices
-
2 auxiliary power outputs (0.5A each) for external devices
-
RS485 communication port reserved for future expansions
-
Compact, durable housing ideal for wall-mounting
-
Multiple fault and alarm output terminals (NO/NC options)
-
Compact, durable housing ideal for wall-mounting
-
Easy to install and operate with user-friendly interface
